| ब्रांड नाम: | GQZ |
| मॉडल नंबर: | XSI140944एन |
| न्यूनतम आदेश मात्रा: | 5पीसी |
| कीमत: | $1029-$1050 |
| डिलीवरी का समय: | आपके भुगतान प्राप्त होने के 3 कार्य दिवस |
| भुगतान की शर्तें: | टी/टी या वेस्टर्न यूनियन या पेपैल |
The XSI141094N Slewing Bearing is a compact, high precision cross roller bearing designed for crane machine parts, CNC systems, rotary platforms, and industrial automation equipment. With dimensions of 984x1164x56mm, this high precision slewing bearing delivers smooth rotation, high rigidity, and excellent load capacity.
Built with a cross cylindrical roller structure, it supports radial, axial, and moment loads simultaneously, making it ideal for crane slewing systems, turntable bearings, and precision positioning applications.
This cross roller slewing bearing offers stable performance, compact design, and long service life, widely used in crane machinery, construction equipment, CNC machine parts, and automation systems.
| Parameter | Specification |
|---|---|
| Model | XSI141094N |
| Inner Diameter (ID) | 984 mm |
| Outer Diameter (OD) | 1164 mm |
| Width (H) | 56 mm |
| Type | Slewing Bearing |
| Structure | Crossed Cylindrical Rollers |
| Material | Bearing Steel |
| Accuracy Class | P5 / P4 optional |
| Preload | Custom |
| Application | Crane Machinery, CNC Systems, Rotary Platforms |
| INA | Weight (Kg) | Da | di | Di | da | La | Li | ni/na | A | B | C | D | Preload | do | m | z |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| XSI140414N | 31 | 484 | 325 | 415 | 411 | 460 | 375 | 24 | 0.04 | 0.04 | 0.06 | 0.06 | 0.01-0.03 | 495 | 5 | 99 |
| XSI140544N | 43 | 614 | 444 | 545 | 541 | 590 | 505 | 32 | 0.04 | 0.04 | 0.07 | 0.07 | 0.01-0.03 | 630 | 6 | 105 |
| XSI140644N | 50 | 714 | 546 | 645 | 641 | 690 | 605 | 36 | 0.05 | 0.05 | 0.08 | 0.08 | 0.01-0.04 | 732 | 6 | 122 |
| XSI140744N | 58 | 814 | 648 | 745 | 741 | 790 | 705 | 40 | 0.05 | 0.05 | 0.09 | 0.08 | 0.01-0.04 | 828 | 6 | 138 |
| XSI140844N | 69 | 914 | 736 | 845 | 841 | 890 | 805 | 40 | 0.06 | 0.06 | 0.09 | 0.09 | 0.01-0.04 | 936 | 8 | 117 |
| XSI140944N | 76 | 1014 | 840 | 945 | 941 | 990 | 905 | 44 | 0.06 | 0.06 | 0.11 | 0.09 | 0.01-0.05 | 1032 | 8 | 129 |
| XSI141094N | 91 | 1164 | 984 | 1095 | 1091 | 1140 | 1055 | 48 | 0.07 | 0.07 | 0.11 | 0.11 | 0.01-0.05 | 1184 | 8 | 148 |
A1: Yes, it is specifically designed for crane slewing and heavy-duty systems.
A2: Its cross roller structure and controlled preload ensure accurate rotation.
A3: Yes, customization is available for preload, precision grade, and materials.
Upgrade your equipment with XSI141094N High Precision Slewing Bearing.
Contact GQZ Bearing today for pricing, samples, or technical consultation!
